Isotra system 25

The variable System 25 window blinds can be fully adapted to your requirements. The unique system offers four control options, a wide range of colours and a sophisticated functional design. Select the colour shade of the lamellas and from one of 15 available colours for the upper cover profile! (It is possible to coordinate everything with wood imitation). The rounded cover profile compared with Isolite plus blinds is optional; therefore, the blind can be selected with or without the upper cover profile.

Benefits & advantages

  • construction with and without upper profile cover
  • variable system for opening – cord, chain, level, engine
  • non-typical variant for bevel and broken windows
  • in between glass panes option
  • colour of the profile according to the RAL sampler or coated in renolite
system-25
previous arrow
next arrow
system-25
previous arrow
next arrow

Dimensions

SYSTEM 25S, SYSTEM 25SW, SYSTEM 25R
  • Width (min / max):
    300 mm / 2000 mm
  • Height (max):
    2200 mm
  • Area (max):
    2,5 m2
SYSTEM 25K
  • Width (min / max):
    400 mm / 2000 mm
  • Height (max):
    2200 mm
  • Area (max):
    2,5 m2
SYSTEM 25L
  • Width (min / max):
    400 mm / 2000 mm
  • Height (max):
    2200 mm
  • Area (max):
    4,4 m2

Handling

  • SYSTEM 25S, 25SM – cord – wand
    Cord for raise and lower (color equal with slat color), hexagonal wand for slats tilting (transparent color).
  • SYSTEM 25SW – In-between glass blind with turn-button for slats tilting..
    Tilt knob for lamellas tilting.
  • SYSTEM 25R – chain
    Chain 3.2mm diameter for raise, lower and tilt (color equal with slat color).
  • SYSTEM 25K – handle
    For raise, lower and tilt (grey color).
  • SYSTEM 25L (large) – chain
    Chain 4.5mm diameter for raise, lower and tilt (color equal with slat color).
  • SYSTEM 25M – motor
    Electric motor: switch for raise, lower and tilt (white color)
    Remote control for raise, lower and tilt (white, silver, black, blue-white color options)
    Plastic components in the colour of the profile. Ladder and cord which are colour coordinated with the lamella.

The atypical version is produced only in SYSTEM 25S, 25SM and 25SW

Color variants

Inspiration
